Abyss MFA5 evo+ 4 channel amplifier
7.175,00 €
Specifications:
Output power rating: 150W x 4 CH
4 ohm at 14.4V(1% THD+N): 150W x 4 CH
2 ohm at 14.4V(1% THD+N): 230W x 4 CH
Mono bridge at 4 ohms (1% THD+N): 450W x 2 CH
Operating voltage (RMS MAX OUTPUT): 9-16V
Power supply: PWM
Output power circuit configuration: MOSFET ClASS-AB
Main PCB Material: FR-4 D / 1 Oz
Miscellaneous Specification:
Soft start sound: YES
Frequency response @-1dB (4ohm 10watt): 5Hz – 30kHz
Damping factor (4ohm/1%): >400
S/N Ration (A-Weight /RMS Power): >92 dB
THD (A-Weight) 10watt: 0.030%
Channel separation: >60dB
Variable Input gain control(1% THD+N): 0.25V~8.0V
Input Impedance: 20k ohm
LED(s): Power/Protect
Protection(Short, Thermal, DC Offset): YES
FUSE: 40A x 2
Dimensions: 210x55x233
Weight: 3.8kg
- Description
- Reviews (0)
Description
New to the Abyss line up, the Abyss MFA5 evo+ series is a product of current day demand: A cost effective audiophile grade amplifier housed a more conservative footprint. (With a nice versatile on-board crossover network)
Easier to install and still retaining its Sound Quality, the MFA5 evo+ is ideal for the daily Audiophile who wants to start venturing to the dark side.
